Schottky diodes

Home > Product Center > Chip Diodes > Schottky diodes

Series overview

LIZ Schottky diode is a low-power ultra-high-speed semiconductor device, the most notable feature is the extremely short reverse recovery time, suitable for high frequency, low voltage, high current rectifier diode, freewheeling diode, protection diode, also useful Used as rectifier diode and small signal detection diode in microwave communication and other circuits.

Application

display more

product	Maximum reverse voltage (V)	Average rectified forward current (A)	Forward voltage (V)	Reverse current (uA)	Package
CDB0130KRL	30	0.1	0.37 @ IF=10mA	7 @ VR=10V	DFN0603-2
CDB0130KRM	30	0.1	0.46 @ IF=10mA	0.3 @ VR=10V	DFN0603-2
CDB0130QRL	30	0.1	0.29 @ IF=10mA 0.30 @ IF=20mA 0.40 @ IF=100mA	30 @ VR=30V	DFN1006-2
CDB0130QRM	30	0.1	0.51 @ IF=100mA	1 @ VR=10V	DFN1006-2
CDB0140QRL	40	0.1	0.34 @ IF=10mA 0.55 @ IF=100mA	10 @ VR=10V 40 @ VR=40V	DFN1006-2
CDB0140QRM	40	0.1	0.36 @ IF=10mA 0.51 @ IF=100mA	1 @ VR=10V 5 @ VR=40V	DFN1006-2
CDB0230QRL	30	0.2	0.50 @ IF=200mA	10 @ VR=10V	DFN1006-2
CDB0230QRM	30	0.2	0.60 @ IF=200mA	1 @ VR=10V	DFN1006-2
CDB0240QRL	40	0.2	0.33 @ IF=10mA 0.52 @ IF=200mA	10 @ VR=10V 40 @ VR=40V	DFN1006-2
CDB0240QRM	40	0.2	0.36 @ IF=10mA 0.60 @ IF=200mA	1 @ VR=10V 5 @ VR=40V	DFN1006-2
CDB0520QRL	20	0.5	0.27 @ IF=10mA 0.46 @ IF=500mA	20 @ VR=10V 30 @ VR=20V	DFN1006-2
CDB0530QRL	30	0.5	0.27 @ IF=10mA 0.46 @ IF=500mA	20 @ VR=10V 40 @ VR=30V	DFN1006-2
CDB0540QRL	40	0.5	0.27 @ IF=10mA 0.46 @ IF=500mA	20 @ VR=10V 50 @ VR=40V	DFN1006-2
